AGM · Series RGP

RGP Series – General Purpose (AGM)

Versatility and reliability for volume applications.

The RGP Series represents absolute versatility in energy storage. Designed with gas recombination AGM technology, this range optimizes operational life while minimizing maintenance. Under the EUROBAT 'General Purpose' classification, it offers a 6 to 9-year design life, utilizing high-purity lead-calcium-tin alloy grids that guarantee a monthly self-discharge rate of less than 2%. It is the ideal solution for security systems, emergency lighting, and domestic UPS, offering a perfect balance between operating cost and proven technical reliability.

Request a quote Models (26) PDF
RGP Series – General Purpose (AGM)
Models
26
Nominal Voltage
6 V, 12 V
Capacity
1.2–28 Ah
Design life
9 years
Warranty
2 years
EUROBAT
6-9 Years (General Purpose)

Key features

  • AGM Technology: Fully sealed, maintenance-free, and leak-proof.
  • High Energy Density: Optimized for critical and rapid discharges.
  • Low Self-Discharge: Pb-Ca alloy allows for long storage periods.
  • Advanced Safety: Safety valves and reinforced ABS container.

Applications

  • UPS and Data Centers
  • Security and Alarm Systems
    Backup power for alarm panels, access control and video surveillance.
  • Emergency Lighting
    Power for emergency luminaires and lighting systems.

Standards and certifications

CE CERTIFIED ISO 9001 / 14001 GB/T19639 IEC 61056 JIS C8702

RGP series models

Each model links to its datasheet with discharge tables, dimensions and charge parameters. Rated capacity at 25 °C; C20 = 20-hour rate.

Model Nominal Voltage Capacity Length (mm) Width (mm) Height (mm) Weight (kgs)Terminal
RGP6-1.2 (formerly RKE6-1.2) 6 V 1.2 Ah (C20) 97 24 52 0.3
RGP6-4.5 (formerly RKE6-4.5) 6 V 4.5 Ah (C20) 70 47 101 0.73
RGP6-20 (formerly RKE6-20) 6 V 20 Ah (C20) 157 83 125 3F17
RGP12-1.2 (formerly RKE12-1.2) 12 V 1.2 Ah (C20) 97 43 52 0.52F1
RGP12-1.3 (formerly RKE12-1.3) 12 V 1.3 Ah (C20) 97 43 52 0.55F1
RGP12-2.3 (formerly RKE12-2.3) 12 V 2.3 Ah (C20) 178 35 61 0.9F1
RGP12-2.6 (formerly RKE12-2.6) 12 V 2.6 Ah (C20) 70 47 101 0.85F1
RGP12-4 (formerly RKE12-4) 12 V 4 Ah (C20) 90 70 101 1.4
RGP12-4SE (formerly RKE12-4SE) 12 V 4 Ah (C20) 90 70 101 1.18
RGP12-4.5 (formerly RKE12-4.5) 12 V 4.5 Ah (C20) 90 70 101 1.47
RGP12-5 (formerly RKE12-5) 12 V 5 Ah (C20) 90 70 101 1.6
RGP12-5.5 (formerly RKE12-5.5) 12 V 5.5 Ah (C20) 151 65 93 1.88
RGP12-6.5 (formerly RKE12-6.5) 12 V 6.5 Ah (C20) 151 65 93 2
RGP12-7 (formerly RKE12-7) 12 V 7 Ah (C20) 151 65 93 2.1
RGP12-7SE (formerly RKE12-7SE) 12 V 7 Ah (C20) 151 65 93 1.8
RGP12-7.2 (formerly RKE12-7.2) 12 V 7.2 Ah (C20) 151 65 93 2.2
RGP12-7.5 (formerly RKE12-7.5) 12 V 7.5 Ah (C20) 151 65 93 2.35
RGP12-9 (formerly RKE12-9) 12 V 9 Ah (C20) 151 65 94 2.55
RGP12-10 (formerly RKE12-10) 12 V 10 Ah (C20) 151 65 110 2.8
RGP12-12 (formerly RKE12-12) 12 V 12 Ah (C20) 151 98 95 3.6
RGP12-17 (formerly RKE12-17) 12 V 17 Ah (C20) 181 77 167 5.1
RGP12-18 (formerly RKE12-18) 12 V 18 Ah (C20) 181 77 167 5.4
RGP12-20 (formerly RKE12-20) 12 V 20 Ah (C20) 181 77 167 5.7
RGP12-24 (formerly RKE12-24) 12 V 24 Ah (C20) 166 175 125 7.8
RGP12-26 (formerly RKE12-26) 12 V 26 Ah (C20) 166 175 125 8.3
RGP12-28 (formerly RKE12-28) 12 V 28 Ah (C20) 165 125 175 8.6

Construction

ComponentMaterial
ContainerABS (Flame Retardant Optional)
CoverABS (Flame Retardant Optional)
ElectrolyteSulphuric acid
NegativeLead
PositiveLead dioxide
Safety ValveRubber
SealantEpoxy Resin
SeparatorFibre Glass
TerminalCopper

Downloads

RGP series datasheets (PDF)
