RGP12-2.6
SERIES RGP · GENERAL PURPOSE (AGM)Versatility and reliability for volume applications.
The RGP12-2.6 is a 12 V, 2.6 Ah (20-hour rate) AGM lead-acid battery from the Rekoser General Purpose (AGM) series. It measures 70 × 47 × 101 mm and weighs 0.85 kg, with F1 terminals. It stores 31 Wh and delivers up to 39 A. Versatility and reliability for volume applications. Typical applications: UPS and Data Centers, Security and Alarm Systems and Emergency Lighting.
Formerly RKE12-2.6.
Main Advantages
- AGM Technology: Fully sealed, maintenance-free, and leak-proof.
- High Energy Density: Optimized for critical and rapid discharges.
- Low Self-Discharge: Pb-Ca alloy allows for long storage periods.
- Advanced Safety: Safety valves and reinforced ABS container.
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 2.6 Ah (C20) |
| Energy | 31 Wh |
| Weight | 0.85 kg |
| Terminal | F1 |
| Dimensions | 70 × 47 × 101 mm |
Main Applications
Quality Standards
RGP12-2.6
GENERAL PURPOSE (AGM)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 6.49A | 5.08A | 4.31A | 2.65A | 1.58A | 0.68A | 0.44A | 0.243A | 0.124A |
| 10.80 V | 7.34A | 5.39A | 4.42A | 2.7A | 1.6A | 0.69A | 0.445A | 0.246A | 0.127A |
| 10.50 V | 8.19A | 5.71A | 4.53A | 2.75A | 1.64A | 0.7A | 0.45A | 0.249A | 0.13A |
| 10.20 V | 8.98A | 5.97A | 4.64A | 2.82A | 1.66A | 0.71A | 0.456A | 0.251A | 0.133A |
| 10.02 V | 9.68A | 6.24A | 4.76A | 2.87A | 1.69A | 0.72A | 0.462A | 0.254A | 0.135A |
| 9.60 V | 10.4A | 6.46A | 4.93A | 2.93A | 1.71A | 0.72A | 0.467A | 0.258A | 0.138A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 12.2W | 9.66W | 8.23W | 5.1W | 3.06W | 1.34W | 0.871W | 0.485W | 0.249W |
| 10.80 V | 13.6W | 10.1W | 8.35W | 5.15W | 3.08W | 1.35W | 0.873W | 0.488W | 0.254W |
| 10.50 V | 15W | 10.6W | 8.48W | 5.2W | 3.11W | 1.36W | 0.876W | 0.49W | 0.258W |
| 10.20 V | 16.2W | 11W | 8.61W | 5.27W | 3.14W | 1.36W | 0.881W | 0.492W | 0.262W |
| 10.02 V | 17.3W | 11.3W | 8.75W | 5.32W | 3.17W | 1.36W | 0.885W | 0.494W | 0.265W |
| 9.60 V | 18.3W | 11.6W | 8.99W | 5.42W | 3.19W | 1.37W | 0.89W | 0.498W | 0.268W |
RGP12-2.6
GENERAL PURPOSE (AGM)Specifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 2.6 Ah (C20) |
| Energy | 31 Wh |
| Cell number | 6 |
| Charge Voltage (25°C) | Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A Float use: 13.6-13.8V (-20mV/C) |
| Max. Discharge Current | 39 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 25 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RGP12-2.6
GENERAL PURPOSE (AGM)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RGP12-2.6 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 70 mm
- Width: 47 mm
- Height: 101 mm
- Total Height: 107 mm
- Weight: 0.85 kg
2. Terminal Configuration (F1)
- Terminals: Ensure your system's connectors match the F1 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A
- Float use: 13.6-13.8V (-20mV/C)
4. Safety and Storage
Maintenance: Sealed AGM technology, maintenance-free and leak-proof.
Position: Can be installed in any orientation, except inverted.
Storage: Store charged, in a cool and dry place, and recharge periodically.
