Versatility and reliability for volume applications.
The RGP12-7 is a 12 V, 7 Ah (20-hour rate) AGM lead-acid battery from the Rekoser General Purpose (AGM) series. It measures 151 × 65 × 93 mm and weighs 2.1 kg. It stores 84 Wh and delivers up to 105 A. Versatility and reliability for volume applications. Typical applications: UPS and Data Centers, Security and Alarm Systems and Emergency Lighting.
Formerly RKE12-7.
Main Advantages
- AGM Technology: Fully sealed, maintenance-free, and leak-proof.
- High Energy Density: Optimized for critical and rapid discharges.
- Low Self-Discharge: Pb-Ca alloy allows for long storage periods.
- Advanced Safety: Safety valves and reinforced ABS container.
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 7 Ah (C20) |
| Energy | 84 Wh |
| Weight | 2.1 kg |
| Dimensions | 151 × 65 × 93 mm |
Main Applications
Quality Standards
RGP12-7
GENERAL PURPOSE (AGM)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 17.5A | 13.7A | 11.6A | 7.13A | 4.25A | 1.84A | 1.19A | 0.65A | 0.33A |
| 10.80 V | 19.8A | 14.5A | 11.9A | 7.28A | 4.31A | 1.86A | 1.2A | 0.66A | 0.34A |
| 10.50 V | 22.1A | 15.4A | 12.2A | 7.41A | 4.4A | 1.89A | 1.21A | 0.67A | 0.35A |
| 10.20 V | 24.2A | 16.1A | 12.5A | 7.58A | 4.48A | 1.91A | 1.23A | 0.68A | 0.36A |
| 10.02 V | 26.1A | 16.8A | 12.8A | 7.71A | 4.55A | 1.93A | 1.24A | 0.69A | 0.36A |
| 9.60 V | 28.1A | 17.4A | 13.3A | 7.9A | 4.61A | 1.95A | 1.26A | 0.7A | 0.37A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 32.9W | 26W | 22.2W | 13.7W | 8.24W | 3.62W | 2.3W | 1.29W | 0.67W |
| 10.80 V | 36.6W | 27.3W | 22.5W | 13.9W | 8.28W | 3.63W | 2.35W | 1.3W | 0.68W |
| 10.50 V | 40.3W | 28.5W | 22.8W | 14W | 8.38W | 3.65W | 2.36W | 1.31W | 0.69W |
| 10.20 V | 43.7W | 29.5W | 23.2W | 14.2W | 8.46W | 3.66W | 2.37W | 1.32W | 0.7W |
| 10.02 V | 46.5W | 30.5W | 23.6W | 14.3W | 8.53W | 3.67W | 2.38W | 1.33W | 0.71W |
| 9.60 V | 49.4W | 31.3W | 24.2W | 14.6W | 8.59W | 3.68W | 2.4W | 1.34W | 0.72W |
RGP12-7
GENERAL PURPOSE (AGM)Specifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 7 Ah (C20) |
| Energy | 84 Wh |
| Cell number | 6 |
| Charge Voltage (25°C) | Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A Float use: 13.6-13.8V (-20mV/C) |
| Max. Charge Current | 2.1 A |
| Max. Discharge Current | 105 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 25 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RGP12-7
GENERAL PURPOSE (AGM)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RGP12-7 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 151 mm
- Width: 65 mm
- Height: 93 mm
- Total Height: 99 mm
- Weight: 2.1 kg
2. Terminals and Polarity
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A
- Float use: 13.6-13.8V (-20mV/C)
4. Safety and Storage
Maintenance: Sealed AGM technology, maintenance-free and leak-proof.
Position: Can be installed in any orientation, except inverted.
Storage: Store charged, in a cool and dry place, and recharge periodically.
