RGP12-6.5
SERIES RGP · GENERAL PURPOSE (AGM)Versatility and reliability for volume applications.
The RGP12-6.5 is a 12 V, 6.5 Ah (20-hour rate) AGM lead-acid battery from the Rekoser General Purpose (AGM) series. It measures 151 × 65 × 93 mm and weighs 2 kg. It stores 78 Wh and delivers up to 105 A. Versatility and reliability for volume applications. Typical applications: UPS and Data Centers, Security and Alarm Systems and Emergency Lighting.
Formerly RKE12-6.5.
Main Advantages
- AGM Technology: Fully sealed, maintenance-free, and leak-proof.
- High Energy Density: Optimized for critical and rapid discharges.
- Low Self-Discharge: Pb-Ca alloy allows for long storage periods.
- Advanced Safety: Safety valves and reinforced ABS container.
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 6.5 Ah (C20) |
| Energy | 78 Wh |
| Weight | 2 kg |
| Dimensions | 151 × 65 × 93 mm |
Main Applications
Quality Standards
RGP12-6.5
GENERAL PURPOSE (AGM)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 16.2A | 12.7A | 10.8A | 6.62A | 3.95A | 1.71A | 1.1A | 0.606A | 0.31A |
| 10.80 V | 18.3A | 13.5A | 11A | 6.76A | 4A | 1.73A | 1.11A | 0.614A | 0.318A |
| 10.50 V | 20.5A | 14.3A | 11.3A | 6.88A | 4.09A | 1.76A | 1.12A | 0.622A | 0.326A |
| 10.20 V | 22.5A | 14.9A | 11.6A | 7.04A | 4.16A | 1.77A | 1.14A | 0.629A | 0.332A |
| 10.02 V | 24.2A | 15.6A | 11.9A | 7.16A | 4.23A | 1.79A | 1.16A | 0.636A | 0.339A |
| 9.60 V | 26.1A | 16.2A | 12.3A | 7.34A | 4.28A | 1.81A | 1.17A | 0.645A | 0.345A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 30.6W | 24.1W | 20.6W | 12.7W | 7.65W | 3.36W | 2.16W | 1.212W | 0.623W |
| 10.80 V | 34W | 25.3W | 20.9W | 12.9W | 7.69W | 3.37W | 2.18W | 1.22W | 0.635W |
| 10.50 V | 37.4W | 26.5W | 21.2W | 13W | 7.78W | 3.39W | 2.19W | 1.225W | 0.645W |
| 10.20 V | 40.5W | 27.4W | 21.5W | 13.2W | 7.85W | 3.4W | 2.2W | 1.231W | 0.655W |
| 10.02 V | 43.2W | 28.3W | 21.9W | 13.3W | 7.92W | 3.4W | 2.21W | 1.236W | 0.662W |
| 9.60 V | 45.9W | 29W | 22.5W | 13.6W | 7.97W | 3.42W | 2.22W | 1.245W | 0.669W |
RGP12-6.5
GENERAL PURPOSE (AGM)Specifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 6.5 Ah (C20) |
| Energy | 78 Wh |
| Cell number | 6 |
| Charge Voltage (25°C) | Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A Float use: 13.6-13.8V (-20mV/C) |
| Max. Charge Current | 2 A |
| Max. Discharge Current | 105 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 25 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RGP12-6.5
GENERAL PURPOSE (AGM)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RGP12-6.5 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 151 mm
- Width: 65 mm
- Height: 93 mm
- Total Height: 99 mm
- Weight: 2 kg
2. Terminals and Polarity
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A
- Float use: 13.6-13.8V (-20mV/C)
4. Safety and Storage
Maintenance: Sealed AGM technology, maintenance-free and leak-proof.
Position: Can be installed in any orientation, except inverted.
Storage: Store charged, in a cool and dry place, and recharge periodically.
