Versatility and reliability for volume applications.
The RGP12-5 is a 12 V, 5 Ah (20-hour rate) AGM lead-acid battery from the Rekoser General Purpose (AGM) series. It measures 90 × 70 × 101 mm and weighs 1.6 kg. It stores 60 Wh and delivers up to 75 A. Versatility and reliability for volume applications. Typical applications: UPS and Data Centers, Security and Alarm Systems and Emergency Lighting.
Formerly RKE12-5.
Main Advantages
- AGM Technology: Fully sealed, maintenance-free, and leak-proof.
- High Energy Density: Optimized for critical and rapid discharges.
- Low Self-Discharge: Pb-Ca alloy allows for long storage periods.
- Advanced Safety: Safety valves and reinforced ABS container.
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 5 Ah (C20) |
| Energy | 60 Wh |
| Weight | 1.6 kg |
| Dimensions | 90 × 70 × 101 mm |
Main Applications
Quality Standards
RGP12-5
GENERAL PURPOSE (AGM)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 12.5A | 9.78A | 8.28A | 5.09A | 3.04A | 1.31A | 0.85A | 0.45A | 0.238A |
| 10.80 V | 14.1A | 10.4A | 8.49A | 5.2A | 3.08A | 1.33A | 0.86A | 0.46A | 0.245A |
| 10.50 V | 15.8A | 11A | 8.7A | 5.29A | 3.15A | 1.35A | 0.87A | 0.47A | 0.25A |
| 10.20 V | 17.3A | 11.5A | 8.93A | 5.42A | 3.2A | 1.37A | 0.88A | 0.48A | 0.256A |
| 10.02 V | 18.6A | 12A | 9.16A | 5.51A | 3.25A | 1.38A | 0.89A | 0.49A | 0.261A |
| 9.60 V | 20A | 12.4A | 9.48A | 5.64A | 3.29A | 1.39A | 0.9A | 0.5A | 0.265A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 23.5W | 18.6W | 15.8W | 9.8W | 5.89W | 2.58W | 1.66W | 0.91W | 0.479W |
| 10.80 V | 26.1W | 19.5W | 16.1W | 9.9W | 5.92W | 2.59W | 1.67W | 0.92W | 0.488W |
| 10.50 V | 28.8W | 20.4W | 16.3W | 10W | 5.99W | 2.6W | 1.68W | 0.93W | 0.496W |
| 10.20 V | 31.2W | 21.1W | 16.6W | 10.1W | 6.04W | 2.61W | 1.69W | 0.94W | 0.504W |
| 10.02 V | 33.2W | 21.8W | 16.8W | 10.2W | 6.09W | 2.62W | 1.7W | 0.95W | 0.509W |
| 9.60 V | 35.3W | 22.3W | 17.3W | 10.4W | 6.13W | 2.63W | 1.71W | 0.96W | 0.515W |
RGP12-5
GENERAL PURPOSE (AGM)Specifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 5 Ah (C20) |
| Energy | 60 Wh |
| Cell number | 6 |
| Charge Voltage (25°C) | Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A Float use: 13.6-13.8V (-20mV/C) |
| Max. Charge Current | 1.5 A |
| Max. Discharge Current | 75 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 25 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RGP12-5
GENERAL PURPOSE (AGM)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RGP12-5 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 90 mm
- Width: 70 mm
- Height: 101 mm
- Total Height: 107 mm
- Weight: 1.6 kg
2. Terminals and Polarity
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A
- Float use: 13.6-13.8V (-20mV/C)
4. Safety and Storage
Maintenance: Sealed AGM technology, maintenance-free and leak-proof.
Position: Can be installed in any orientation, except inverted.
Storage: Store charged, in a cool and dry place, and recharge periodically.
