RGP12-10
SERIES RGP · GENERAL PURPOSE (AGM)Versatility and reliability for volume applications.
The RGP12-10 is a 12 V, 10 Ah (20-hour rate) AGM lead-acid battery from the Rekoser General Purpose (AGM) series. It measures 151 × 65 × 110 mm and weighs 2.8 kg. It stores 120 Wh and delivers up to 135 A. Versatility and reliability for volume applications. Typical applications: UPS and Data Centers, Security and Alarm Systems and Emergency Lighting.
Formerly RKE12-10.
Main Advantages
- AGM Technology: Fully sealed, maintenance-free, and leak-proof.
- High Energy Density: Optimized for critical and rapid discharges.
- Low Self-Discharge: Pb-Ca alloy allows for long storage periods.
- Advanced Safety: Safety valves and reinforced ABS container.
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 10 Ah (C20) |
| Energy | 120 Wh |
| Weight | 2.8 kg |
| Dimensions | 151 × 65 × 110 mm |
Main Applications
Quality Standards
RGP12-10
GENERAL PURPOSE (AGM)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 25A | 19.6A | 16.6A | 10.2A | 6.07A | 2.63A | 1.69A | 0.93A | 0.48A |
| 10.80 V | 28.2A | 20.7A | 17A | 10.4A | 6.16A | 2.66A | 1.71A | 0.95A | 0.49A |
| 10.50 V | 31.5A | 21.9A | 17.4A | 10.6A | 6.29A | 2.7A | 1.73A | 0.96A | 0.5A |
| 10.20 V | 34.5A | 23A | 17.9A | 10.8A | 6.4A | 2.73A | 1.75A | 0.97A | 0.51A |
| 10.02 V | 37.2A | 24A | 18.3A | 11A | 6.5A | 2.76A | 1.78A | 0.98A | 0.52A |
| 9.60 V | 40.1A | 24.9A | 19A | 11.3A | 6.58A | 2.78A | 1.8A | 0.99A | 0.53A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 47W | 37.1W | 31.6W | 19.6W | 11.8W | 5.17W | 3.35W | 1.86W | 0.96W |
| 10.80 V | 52.3W | 38.9W | 32.1W | 19.8W | 11.8W | 5.18W | 3.36W | 1.88W | 0.98W |
| 10.50 V | 57.6W | 40.7W | 32.6W | 20W | 12W | 5.22W | 3.37W | 1.88W | 0.99W |
| 10.20 V | 62.4W | 42.2W | 33.1W | 20.3W | 12.1W | 5.23W | 3.39W | 1.89W | 1.01W |
| 10.02 V | 66.4W | 43.6W | 33.7W | 20.5W | 12.2W | 5.23W | 3.41W | 1.9W | 1.02W |
| 9.60 V | 70.6W | 44.7W | 34.6W | 20.9W | 12.3W | 5.26W | 3.42W | 1.91W | 1.03W |
RGP12-10
GENERAL PURPOSE (AGM)Specifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 10 Ah (C20) |
| Energy | 120 Wh |
| Cell number | 6 |
| Charge Voltage (25°C) | Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A Float use: 13.6-13.8V (-20mV/C) |
| Max. Charge Current | 3 A |
| Max. Discharge Current | 135 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 25 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RGP12-10
GENERAL PURPOSE (AGM)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RGP12-10 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 151 mm
- Width: 65 mm
- Height: 110 mm
- Total Height: 117 mm
- Weight: 2.8 kg
2. Terminals and Polarity
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A
- Float use: 13.6-13.8V (-20mV/C)
4. Safety and Storage
Maintenance: Sealed AGM technology, maintenance-free and leak-proof.
Position: Can be installed in any orientation, except inverted.
Storage: Store charged, in a cool and dry place, and recharge periodically.
