RXG2-400
SERIES RXG · EXTENDED GEL (2V)Maximum GEL longevity (2V). Deep-cycle endurance for critical infrastructure.
The RXG2-400 is a 2 V, 400 Ah (10-hour rate) GEL Deep Cycle lead-acid battery from the Rekoser eXtended Gel (2V) series. It measures 210 × 176 × 330 mm and weighs 25.5 kg, with F10 terminals. It stores 800 Wh and delivers up to 2000 A. Maximum GEL longevity (2V). Deep-cycle endurance for critical infrastructure. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and UPS and Data Centers.
Formerly RKG2-400.
Main Advantages
- Recovery: Superior performance after deep discharges
- Stable: Low electrolyte stratification thanks to eXtended Gel technology
- Longevity: Excellent cyclic life in harsh conditions (Very Long Life >12 years design life)
- Gel Tech: Premium thixotropic gel electrolyte with high thermal stability
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 400 Ah (C10) |
| Energy | 800 Wh |
| Weight | 25.5 kg |
| Terminal | F10 |
| Dimensions | 210 × 176 × 330 mm |
Main Applications
Quality Standards
RXG2-400
EXTENDED GEL (2V)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 1.80 V | 321A | 219A | 98.9A | 69.1A | 40A | 21A |
| 1.75 V | 334A | 226A | 102A | 71.2A | 40.3A | 21.1A |
| 1.70 V | 342A | 230A | 103A | 71.7A | 40.5A | 21.3A |
| 1.65 V | 353A | 236A | 103A | 72.2A | 40.6A | 21.3A |
| 1.60 V | 360A | 240A | 104A | 72.6A | 40.7A | 21.4A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 1.80 V | 601W | 416W | 194W | 136W | 79.6W | 42W |
| 1.75 V | 624W | 429W | 200W | 140W | 80.2W | 42.3W |
| 1.70 V | 640W | 438W | 201W | 141W | 80.6W | 42.5W |
| 1.65 V | 660W | 449W | 203W | 142W | 80.9W | 42.7W |
| 1.60 V | 673W | 456W | 204W | 143W | 81W | 42.8W |
RXG2-400
EXTENDED GEL (2V)Specifications
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 400 Ah (C10) |
| Energy | 800 Wh |
| Cell number | 1 |
| Charge Voltage (25°C) | Cycle use: 2.35-2.40V (-5mV/C) Float use: 2.25-2.29V (-3mV/C) |
| Max. Charge Current | 80 A |
| Max. Discharge Current | 2000 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RXG2-400
EXTENDED GEL (2V)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RXG2-400 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 210 mm
- Width: 176 mm
- Height: 330 mm
- Total Height: 367 mm
- Weight: 25.5 kg
2. Terminal Configuration (F10)
- Terminals: Ensure your system's connectors match the F10 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 2.35-2.40V (-5mV/C)
- Float use: 2.25-2.29V (-3mV/C)
4. Safety and Storage
Maintenance: Sealed gel battery, maintenance-free and leak-proof.
Charging: Keep to the stated charge voltage: gel is sensitive to overcharging.
Cycling: Recharge fully after every discharge; never leave it discharged.
Storage: Store charged, in a cool and dry place, and recharge periodically.
