RXG2-300
SERIES RXG · EXTENDED GEL (2V)Maximum GEL longevity (2V). Deep-cycle endurance for critical infrastructure.
The RXG2-300 is a 2 V, 300 Ah (10-hour rate) GEL Deep Cycle lead-acid battery from the Rekoser eXtended Gel (2V) series. It measures 171 × 151 × 330 mm and weighs 18.5 kg, with F10 terminals. It stores 600 Wh and delivers up to 1500 A. Maximum GEL longevity (2V). Deep-cycle endurance for critical infrastructure. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and UPS and Data Centers.
Formerly RKG2-300.
Main Advantages
- Recovery: Superior performance after deep discharges
- Stable: Low electrolyte stratification thanks to eXtended Gel technology
- Longevity: Excellent cyclic life in harsh conditions (Very Long Life >12 years design life)
- Gel Tech: Premium thixotropic gel electrolyte with high thermal stability
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 300 Ah (C10) |
| Energy | 600 Wh |
| Weight | 18.5 kg |
| Terminal | F10 |
| Dimensions | 171 × 151 × 330 mm |
Main Applications
Quality Standards
RXG2-300
EXTENDED GEL (2V)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 1.80 V | 241A | 164A | 74.2A | 51.8A | 30A | 15.8A |
| 1.75 V | 250A | 169A | 76.5A | 53.4A | 30.2A | 15.9A |
| 1.70 V | 257A | 173A | 77A | 53.8A | 30.4A | 16A |
| 1.65 V | 265A | 177A | 77.6A | 54.1A | 30.5A | 16A |
| 1.60 V | 270A | 180A | 78A | 54.5A | 30.5A | 16A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 1.80 V | 451W | 312W | 145W | 102W | 59.7W | 31.5W |
| 1.75 V | 468W | 322W | 150W | 105W | 60.1W | 31.7W |
| 1.70 V | 480W | 328W | 151W | 106W | 60.5W | 31.9W |
| 1.65 V | 495W | 337W | 152W | 107W | 60.7W | 32W |
| 1.60 V | 505W | 342W | 153W | 107W | 60.8W | 32.1W |
RXG2-300
EXTENDED GEL (2V)Specifications
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 300 Ah (C10) |
| Energy | 600 Wh |
| Cell number | 1 |
| Charge Voltage (25°C) | Cycle use: 2.35-2.40V (-5mV/C) Float use: 2.25-2.29V (-3mV/C) |
| Max. Charge Current | 60 A |
| Max. Discharge Current | 1500 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RXG2-300
EXTENDED GEL (2V)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RXG2-300 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 171 mm
- Width: 151 mm
- Height: 330 mm
- Total Height: 364 mm
- Weight: 18.5 kg
2. Terminal Configuration (F10)
- Terminals: Ensure your system's connectors match the F10 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 2.35-2.40V (-5mV/C)
- Float use: 2.25-2.29V (-3mV/C)
4. Safety and Storage
Maintenance: Sealed gel battery, maintenance-free and leak-proof.
Charging: Keep to the stated charge voltage: gel is sensitive to overcharging.
Cycling: Recharge fully after every discharge; never leave it discharged.
Storage: Store charged, in a cool and dry place, and recharge periodically.
