ROV12-150
SERIES ROV · OPZV (TUBULAR GEL)The best of lead. Maintenance-free with extreme service life.
The ROV12-150 is a 12 V, 150 Ah (20-hour rate) OPzV lead-acid battery from the Rekoser OPzV (Tubular Gel) series. It measures 532 × 207 × 209 mm and weighs 58.5 kg, with F10 terminals. It stores 1.8 kWh and delivers up to 875 A. The best of lead. Maintenance-free with extreme service life. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and Railway Signaling and Infrastructure.
Formerly RKV12-150.
Main Advantages
- Combination: Tubular plates with gel electrolyte
- Maintenance: Zero maintenance required
- Durability: 20 years design life at 20ºC
- Install: Can be installed horizontally in racks
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 150 Ah (C20) |
| Energy | 1800 Wh |
| Weight | 58.5 kg |
| Terminal | F10 |
| Dimensions | 532 × 207 × 209 mm |
Main Applications
Quality Standards
ROV12-150
OPZV (TUBULAR GEL)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|
| 10.8 V | 151A | 139A | 111A | 72.6A | 36.1A | 25.9A | 14.3A | 7.5A |
| 10.5 V | 160A | 147A | 115A | 75A | 37.2A | 26.7A | 14.3A | 7.55A |
| 10.2 V | 167A | 152A | 118A | 76.5A | 37.5A | 26.9A | 14.4A | 7.6A |
| 9.9 V | 175A | 158A | 122A | 78.5A | 37.7A | 27.1A | 14.5A | 7.62A |
| 9.6 V | 180A | 162A | 125A | 79.7A | 37.9A | 27.2A | 14.5A | 7.64A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|
| 10.8 V | 272W | 255W | 208W | 138W | 70.7W | 51W | 28.4W | 15W |
| 10.5 V | 288W | 269W | 216W | 142W | 72.9W | 52.6W | 28.5W | 15.1W |
| 10.2 V | 301W | 279W | 221W | 145W | 73.4W | 53W | 28.7W | 15.2W |
| 9.9 V | 314W | 289W | 228W | 149W | 73.9W | 53.3W | 28.8W | 15.2W |
| 9.6 V | 324W | 296W | 233W | 151W | 74.4W | 53.7W | 28.9W | 15.3W |
ROV12-150
OPZV (TUBULAR GEL)Specifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 150 Ah (C20) |
| Energy | 1800 Wh |
| Cell number | 6 |
| Charge Voltage (25°C) | Cycle use: 13.80-14.10V (-30mV/ºC/cell) Float use: 13.50-13.80V (-18mV/ºC/cell) |
| Max. Charge Current | 28 A |
| Max. Discharge Current | 875 A |
| Internal Resistance | 5.2 mΩ |
| Self Discharge | 2 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS(UL94-V0 optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Immobilized Gel |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
ROV12-150
OPZV (TUBULAR GEL)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER ROV12-150 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 532 mm
- Width: 207 mm
- Height: 209 mm
- Total Height: 209 mm
- Weight: 58.5 kg
2. Terminal Configuration (F10)
- Terminals: Ensure your system's connectors match the F10 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 13.80-14.10V (-30mV/ºC/cell)
- Float use: 13.50-13.80V (-18mV/ºC/cell)
4. Safety and Storage
Maintenance: Immobilised gel and tubular plate: sealed, no water topping up.
Position: Upright, or horizontal on a rack.
Charging: Keep to the stated charge voltage: gel is sensitive to overcharging.
Storage: Store charged, in a cool and dry place, and recharge periodically.
