RDG12-60
SERIES RDG · DEEP GELDeep cycling with full recovery from deep discharge.
The RDG12-60 is a 12 V, 60 Ah (10-hour rate) GEL Deep Cycle lead-acid battery from the Rekoser Deep Gel series. It measures 260 × 168 × 211 mm and weighs 20 kg, with F11 terminals. It stores 720 Wh. Deep cycling with full recovery from deep discharge. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and UPS and Data Centers.
Formerly RKG12-60.
Main Advantages
- Recovery: Superior performance after deep discharges
- Stable: Low electrolyte stratification
- Longevity: Excellent cycle life in harsh conditions
- Gel Tech: Thixotropic gel electrolyte
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 60 Ah (C10) |
| Energy | 720 Wh |
| Weight | 20 kg |
| Terminal | F11 |
| Dimensions | 260 × 168 × 211 mm |
Main Applications
Quality Standards
RDG12-60
DEEP GELGraphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|
| 10.80 V | 106A | 85.1A | 53.6A | 33.9A | 14.6A | 10.2A | 6A | 3.15A |
| 10.50 V | 112A | 89.9A | 55.6A | 35A | 15A | 10.5A | 6.04A | 3.17A |
| 10.20 V | 117A | 93.1A | 57A | 35.7A | 15.1.A | 10.6A | 6.08A | 3.19A |
| 10.02 V | 122A | 96.6A | 58.8A | 36.6A | 15.2A | 10.6A | 6.1A | 3.2A |
| 9.60 V | 126A | 99A | 60A | 37.2A | 15.3A | 10.7A | 6.11A | 3.21A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|
| 10.80 V | 1143W | 935W | 601W | 387W | 171W | 120W | 71.6W | 37.8W |
| 10.50 V | 1211W | 987W | 624W | 399W | 176W | 124W | 72.1W | 38.1W |
| 10.20 V | 1266W | 1022W | 640W | 407W | 178W | 125W | 72.6W | 38.3W |
| 10.02 V | 1320W | 1061W | 660W | 418W | 179W | 126W | 72.8W | 38.4W |
| 9.60 V | 1361W | 1087W | 673W | 424W | 180W | 127W | 72.9W | 38.5W |
RDG12-60
DEEP GELSpecifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 60 Ah (C10) |
| Energy | 720 Wh |
| Cell number | 6 |
| Charge Voltage (25°C) | Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A Float use: 13.6-13.8V (-20mV/C) |
| Max. Charge Current | 18 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RDG12-60
DEEP GELQuick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RDG12-60 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 260 mm
- Width: 168 mm
- Height: 211 mm
- Total Height: 216 mm
- Weight: 20 kg
2. Terminal Configuration (F11)
- Terminals: Ensure your system's connectors match the F11 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A
- Float use: 13.6-13.8V (-20mV/C)
4. Safety and Storage
Maintenance: Sealed gel battery, maintenance-free and leak-proof.
Charging: Keep to the stated charge voltage: gel is sensitive to overcharging.
Cycling: Recharge fully after every discharge; never leave it discharged.
Storage: Store charged, in a cool and dry place, and recharge periodically.
