RDG12-55
SERIES RDG · DEEP GELDeep cycling with full recovery from deep discharge.
The RDG12-55 is a 12 V, 55 Ah (10-hour rate) GEL Deep Cycle lead-acid battery from the Rekoser Deep Gel series. It measures 229 × 138 × 208 mm and weighs 17 kg, with F11 terminals. It stores 660 Wh and delivers up to 500 A. Deep cycling with full recovery from deep discharge. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and UPS and Data Centers.
Formerly RKG12-55.
Main Advantages
- Recovery: Superior performance after deep discharges
- Stable: Low electrolyte stratification
- Longevity: Excellent cycle life in harsh conditions
- Gel Tech: Thixotropic gel electrolyte
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 55 Ah (C10) |
| Energy | 660 Wh |
| Weight | 17 kg |
| Terminal | F11 |
| Dimensions | 229 × 138 × 208 mm |
Main Applications
Quality Standards
RDG12-55
DEEP GELGraphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 86.5A | 77.5A | 70.6A | 49.6A | 32A | 14.2A | 9.53A | 5.36A | 2.82A |
| 10.80 V | 101A | 86.1A | 77.5A | 52.6A | 33.5A | 14.7A | 9.76A | 5.5A | 2.89A |
| 10.50 V | 114A | 94.7A | 83.1A | 55A | 34.6A | 15A | 10A | 5.61A | 2.94A |
| 10.20 V | 131A | 102A | 89.5A | 57A | 35.4A | 15.2A | 10.1A | 5.69A | 3A |
| 10.02 V | 147A | 112A | 94.7A | 59.2A | 36.2A | 15.4A | 10.2A | 5.76A | 3.07A |
| 9.60 V | 165A | 122A | 101A | 61.9A | 37.2A | 15.6A | 10.4A | 5.83A | 3.14A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 163W | 147W | 135W | 95.5W | 62.2W | 27.9W | 18.8W | 10.7W | 5.67W |
| 10.80 V | 187W | 162W | 147W | 100W | 64.3W | 28.6W | 19.2W | 10.9W | 5.77W |
| 10.50 V | 209W | 176W | 156W | 104W | 65.9W | 28.9W | 19.4W | 11W | 5.83W |
| 10.20 V | 237W | 187W | 166W | 107W | 66.8W | 29.1W | 19.5W | 11.1W | 5.91W |
| 10.02 V | 263W | 204W | 174W | 110W | 67.9W | 29.3W | 19.6W | 11.2W | 6W |
| 9.60 V | 291W | 219W | 183W | 114W | 69.3W | 29.4W | 19.7W | 11.3W | 6.1W |
RDG12-55
DEEP GELSpecifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 55 Ah (C10) |
| Energy | 660 Wh |
| Cell number | 6 |
| Charge Voltage (25°C) | Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A Float use: 13.6-13.8V (-20mV/C) |
| Max. Charge Current | 13.75 A |
| Max. Discharge Current | 500 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RDG12-55
DEEP GELQuick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RDG12-55 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 229 mm
- Width: 138 mm
- Height: 208 mm
- Total Height: 212 mm
- Weight: 17 kg
2. Terminal Configuration (F11)
- Terminals: Ensure your system's connectors match the F11 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A
- Float use: 13.6-13.8V (-20mV/C)
4. Safety and Storage
Maintenance: Sealed gel battery, maintenance-free and leak-proof.
Charging: Keep to the stated charge voltage: gel is sensitive to overcharging.
Cycling: Recharge fully after every discharge; never leave it discharged.
Storage: Store charged, in a cool and dry place, and recharge periodically.
