RDC6-200G
SERIES RDC · DEEP CYCLE (AGM)Endurance for frequent charge/discharge cycling.
The RDC6-200G is a 6 V, 200 Ah (10-hour rate) AGM Deep Cycle lead-acid battery from the Rekoser Deep Cycle (AGM) series. It measures 264 × 180 × 247 mm and weighs 30 kg, with F12 terminals. It stores 1.2 kWh and delivers up to 1200 A. Endurance for frequent charge/discharge cycling. Typical applications: Solar/Wind Energy Systems and Light Electric Vehicles.
Formerly RKC6-200G.
Main Advantages
- Cycling: Optimized for more than 400 cycles at 80% DOD
- Materials: Specialized active material and thick plates
- Versatility: Suitable for both motive and stationary use
- Efficiency: High recharge acceptance
| Nominal Voltage | 6 V |
|---|---|
| Capacity (25ºC) | 200 Ah (C10) |
| Energy | 1200 Wh |
| Weight | 30 kg |
| Terminal | F12 |
| Dimensions | 264 × 180 × 247 mm |
Main Applications
Quality Standards
RDC6-200G
DEEP CYCLE (AGM)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 4.8 V | 525A | 435A | 345A | 215A | 128A | 53.8A | 38.1A | 20.2A | 10.7A |
| 4.95 V | 490A | 410A | 325A | 207A | 126A | 52.9A | 37.8A | 20.1A | 10.7A |
| 5.1 V | 455A | 385A | 305A | 199A | 124A | 52A | 37.5A | 20A | 10.6A |
| 5.25 V | 420A | 358A | 285A | 191A | 121A | 51.1A | 37A | 20A | 10.5A |
| 5.4 V | 370A | 328A | 263A | 181A | 117A | 50A | 36.4A | 19.2A | 10.4A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 4.8 V | 865W | 715W | 587W | 378W | 250W | 97.9W | 70.7W | W | W |
| 4.95 V | 819W | 680W | 559W | 364W | 245W | 96.6W | 70.1W | W | W |
| 5.1 V | 773W | 644W | 541W | 350W | 241W | 95.3W | 69.5W | W | W |
| 5.25 V | 727W | 606W | 523W | 336W | 236W | 93.9W | 69W | W | W |
| 5.4 V | 579W | 576W | 492W | 322W | 231W | 92.9W | 68.4W | W | W |
RDC6-200G
DEEP CYCLE (AGM)Specifications
| Nominal Voltage | 6 V |
|---|---|
| Capacity (25ºC) | 200 Ah (C10) |
| Energy | 1200 Wh |
| Cell number | 3 |
| Charge Voltage (25°C) | Cycle use: 7.35-7.45V (-30mV/C), max. Current 2.1A Float use: 6.8-6.9V (-20mV/C) |
| Max. Charge Current | 39 A |
| Max. Discharge Current | 1200 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RDC6-200G
DEEP CYCLE (AGM)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RDC6-200G battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 264 mm
- Width: 180 mm
- Height: 247 mm
- Total Height: 250 mm
- Weight: 30 kg
2. Terminal Configuration (F12)
- Terminals: Ensure your system's connectors match the F12 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 7.35-7.45V (-30mV/C), max. Current 2.1A
- Float use: 6.8-6.9V (-20mV/C)
4. Safety and Storage
Maintenance: Sealed AGM technology, maintenance-free and leak-proof.
Cycling: Recharge fully after every discharge; never leave it discharged.
Position: Can be installed in any orientation, except inverted.
Storage: Store charged, in a cool and dry place, and recharge periodically.
