ROV6-300
SERIES ROV · OPZV (TUBULAR GEL)The best of lead. Maintenance-free with extreme service life.
The ROV6-300 is a 6 V, 300 Ah (10-hour rate) OPzV lead-acid battery from the Rekoser OPzV (Tubular Gel) series. It measures 295 × 178 × 405 mm and weighs 52.5 kg, with F10 terminals. It stores 1.8 kWh and delivers up to 1250 A. The best of lead. Maintenance-free with extreme service life. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and Railway Signaling and Infrastructure.
Formerly RKV6-300.
Main Advantages
- Combination: Tubular plates with gel electrolyte
- Maintenance: Zero maintenance required
- Durability: 20 years design life at 20ºC
- Install: Can be installed horizontally in racks
| Nominal Voltage | 6 V |
|---|---|
| Capacity (25ºC) | 300 Ah (C10) |
| Energy | 1800 Wh |
| Weight | 52.5 kg |
| Terminal | F10 |
| Dimensions | 295 × 178 × 405 mm |
Main Applications
Quality Standards
ROV6-300
OPZV (TUBULAR GEL)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 5.40 V | 222A | 145A | 72.2A | 51.8A | 30A | 16.2A |
| 5.25 V | 231A | 150A | 74.4A | 53.4A | 30.2A | 16.3A |
| 5.10 V | 237A | 153A | 74.9A | 53.8A | 30.4A | 16.4A |
| 4.95 V | 244A | 157A | 75.4A | 54.1A | 30.5A | 16.5A |
| 4.80 V | 249A | 159A | 75.9A | 54.5A | 30.5A | 16.5A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 5.40 V | 516W | 276W | 141W | 102W | 59.7W | 31.2W |
| 5.25 V | 432W | 285W | 146W | 105W | 60W | 31.4W |
| 5.10 V | 442W | 291W | 147W | 106W | 60.5W | 31.6W |
| 4.95 V | 456W | 298W | 148W | 107W | 60.7W | 31.8W |
| 4.80 V | 466W | 303W | 149W | 107W | 60.8W | 32W |
ROV6-300
OPZV (TUBULAR GEL)Specifications
| Nominal Voltage | 6 V |
|---|---|
| Capacity (25ºC) | 300 Ah (C10) |
| Energy | 1800 Wh |
| Cell number | 3 |
| Charge Voltage (25°C) | Cycle use: 7.05-7.20V (-5mV/ºC/cell) Float use: 6.75-6.90V (-3mV/ºC/cell) |
| Max. Charge Current | 60 A |
| Max. Discharge Current | 1250 A |
| Internal Resistance | 4.7 mΩ |
| Self Discharge | 2 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS(UL94-V0 optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Immobilized Gel |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
ROV6-300
OPZV (TUBULAR GEL)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER ROV6-300 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 295 mm
- Width: 178 mm
- Height: 405 mm
- Total Height: 405 mm
- Weight: 52.5 kg
2. Terminal Configuration (F10)
- Terminals: Ensure your system's connectors match the F10 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 7.05-7.20V (-5mV/ºC/cell)
- Float use: 6.75-6.90V (-3mV/ºC/cell)
4. Safety and Storage
Maintenance: Immobilised gel and tubular plate: sealed, no water topping up.
Position: Upright, or horizontal on a rack.
Charging: Keep to the stated charge voltage: gel is sensitive to overcharging.
Storage: Store charged, in a cool and dry place, and recharge periodically.
