ROV6-250
SERIES ROV · OPZV (TUBULAR GEL)The best of lead. Maintenance-free with extreme service life.
The ROV6-250 is a 6 V, 250 Ah (10-hour rate) OPzV lead-acid battery from the Rekoser OPzV (Tubular Gel) series. It measures 295 × 178 × 408 mm and weighs 46.5 kg, with F10 terminals. It stores 1.5 kWh and delivers up to 1250 A. The best of lead. Maintenance-free with extreme service life. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and Railway Signaling and Infrastructure.
Formerly RKV6-250.
Main Advantages
- Combination: Tubular plates with gel electrolyte
- Maintenance: Zero maintenance required
- Durability: 20 years design life at 20ºC
- Install: Can be installed horizontally in racks
| Nominal Voltage | 6 V |
|---|---|
| Capacity (25ºC) | 250 Ah (C10) |
| Energy | 1500 Wh |
| Weight | 46.5 kg |
| Terminal | F10 |
| Dimensions | 295 × 178 × 408 mm |
Main Applications
Quality Standards
ROV6-250
OPZV (TUBULAR GEL)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 5.40 V | 185A | 116A | 60.1A | 43.1A | 25A | 13.2A |
| 5.25 V | 192A | 125A | 62A | 44.5A | 25.1A | 13.3A |
| 5.10 V | 197A | 127A | 62.3A | 44.7A | 25.3A | 13.3A |
| 4.95 V | 204A | 131A | 62.8A | 45.1A | 25.3A | 13.5A |
| 4.80 V | 207A | 132A | 63.2A | 45.3A | 25.5A | 13.5A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 5.40 V | 346W | 230W | 117W | 85W | 49.7W | 26.5W |
| 5.25 V | 360W | 273W | 121W | 87.6W | 50W | 26.6W |
| 5.10 V | 368W | 242W | 122W | 88.2W | 50.3W | 26.8W |
| 4.95 V | 380W | 248W | 123W | 88.8W | 50.5W | 26.8W |
| 4.80 V | 387W | 252W | 124W | 89.3W | 50.6W | 27W |
ROV6-250
OPZV (TUBULAR GEL)Specifications
| Nominal Voltage | 6 V |
|---|---|
| Capacity (25ºC) | 250 Ah (C10) |
| Energy | 1500 Wh |
| Cell number | 3 |
| Charge Voltage (25°C) | Cycle use: 7.05-7.20V (-5mV/ºC/cell) Float use: 6.75-6.90V (-3mV/ºC/cell) |
| Max. Charge Current | 60 A |
| Max. Discharge Current | 1250 A |
| Internal Resistance | 4.7 mΩ |
| Self Discharge | 2 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS(UL94-V0 optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Immobilized Gel |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
ROV6-250
OPZV (TUBULAR GEL)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER ROV6-250 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 295 mm
- Width: 178 mm
- Height: 408 mm
- Total Height: 408 mm
- Weight: 46.5 kg
2. Terminal Configuration (F10)
- Terminals: Ensure your system's connectors match the F10 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 7.05-7.20V (-5mV/ºC/cell)
- Float use: 6.75-6.90V (-3mV/ºC/cell)
4. Safety and Storage
Maintenance: Immobilised gel and tubular plate: sealed, no water topping up.
Position: Upright, or horizontal on a rack.
Charging: Keep to the stated charge voltage: gel is sensitive to overcharging.
Storage: Store charged, in a cool and dry place, and recharge periodically.
