ROV12-75
SERIES ROV · OPZV (TUBULAR GEL)The best of lead. Maintenance-free with extreme service life.
The ROV12-75 is a 12 V, 75 Ah (10-hour rate) OPzV lead-acid battery from the Rekoser OPzV (Tubular Gel) series. It measures 330 × 171 × 214 mm and weighs 30.5 kg, with F10 terminals. It stores 900 Wh and delivers up to 400 A. The best of lead. Maintenance-free with extreme service life. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and Railway Signaling and Infrastructure.
Formerly RKV12-75.
Main Advantages
- Combination: Tubular plates with gel electrolyte
- Maintenance: Zero maintenance required
- Durability: 20 years design life at 20ºC
- Install: Can be installed horizontally in racks
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 75 Ah (C10) |
| Energy | 900 Wh |
| Weight | 30.5 kg |
| Terminal | F10 |
| Dimensions | 330 × 171 × 214 mm |
Main Applications
Quality Standards
ROV12-75
OPZV (TUBULAR GEL)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 11.1 V | 58A | 37.9A | 18.9A | 13.6A | 7.5A | 3.96A |
| 10.8 V | 62.4A | 40.8A | 19.8A | 14.6A | 8A | 4.21A |
| 10.5 V | 64.7A | 42.1A | 20A | 15A | 8.04 16.0A | 4.24A |
| 10.2 V | 66.5A | 42.9A | 20.3A | 15.1A | 8.1A | 4.27A |
| 9.9 V | 68.5A | 44A | 20.5A | 15.2A | 8.13A | 4.28A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 11.1 V | 110W | 72.8W | 37.2W | 26.9W | 15W | 7.92W |
| 10.8 V | 117W | 77.5W | 38.8W | 28.8W | 15.9W | 8.32W |
| 10.5 V | 122W | 79.5W | 39.1W | 29.5W | W | 8.4W |
| 10.2 V | 124W | 80.3W | 39.2W | 29.5W | 16W | 8.4W |
| 9.9 V | 127W | 81.9W | 39.3W | 29.6W | 16.1W | 8.45W |
ROV12-75
OPZV (TUBULAR GEL)Specifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 75 Ah (C10) |
| Energy | 900 Wh |
| Charge Voltage (25°C) | Cycle use: 13.80-14.10V (-30mV/ºC/cell) Float use: 13.50-13.80V (-18mV/ºC/cell) |
| Max. Charge Current | 16 A |
| Max. Discharge Current | 400 A |
| Internal Resistance | 7.8 mΩ |
| Self Discharge | 2 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS(UL94-V0 optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Immobilized Gel |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
ROV12-75
OPZV (TUBULAR GEL)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER ROV12-75 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 330 mm
- Width: 171 mm
- Height: 214 mm
- Total Height: 214 mm
- Weight: 30.5 kg
2. Terminal Configuration (F10)
- Terminals: Ensure your system's connectors match the F10 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 13.80-14.10V (-30mV/ºC/cell)
- Float use: 13.50-13.80V (-18mV/ºC/cell)
4. Safety and Storage
Maintenance: Immobilised gel and tubular plate: sealed, no water topping up.
Position: Upright, or horizontal on a rack.
Charging: Keep to the stated charge voltage: gel is sensitive to overcharging.
Storage: Store charged, in a cool and dry place, and recharge periodically.
