ROS2-3300
SERIES ROS · OPZS (FLOODED)The energy tank. 20+ years of proven service life.
The ROS2-3300 is a 2 V, 3300 Ah (10-hour rate) OPzS lead-acid battery from the Rekoser OPzS (Flooded) series. It measures 576 × 212 × 771 mm and weighs 162 kg, with F10 terminals. It stores 6.6 kWh and delivers up to 6000 A. The energy tank. 20+ years of proven service life. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and Railway Signaling and Infrastructure.
Formerly RKS2-3300.
Main Advantages
- Technology: Vented tubular plates with liquid electrolyte
- Maintenance: Periodic topping up with distilled water required
- Durability: Over 20 years proven design life at 20ºC
- Control: Transparent container for easy electrolyte level monitoring
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 3300 Ah (C10) |
| Energy | 6600 Wh |
| Weight | 162 kg |
| Terminal | F10 |
| Dimensions | 576 × 212 × 771 mm |
Main Applications
Quality Standards
ROS2-3300
OPZS (FLOODED)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 1.80 V | 1932A | 1389A | 820A | 597A | 330A | 178A |
| 1.75 V | 2128A | 1578A | 868A | 607A | 332A | 179A |
| 1.70 V | 2219A | 1677A | 913A | 611A | 334A | 180A |
| 1.65 V | 2364A | 1707A | 926A | 620A | 335A | 181A |
| 1.60 V | 2412A | 1733A | 931A | 624A | 336A | 181A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 1.80 V | 3474W | 2552W | 1570W | 1177W | 657W | 356W |
| 1.75 V | 3826W | 2899W | 1670W | 1196W | 661W | 359W |
| 1.70 V | 3990W | 3081W | 1766W | 1205W | 667W | 362W |
| 1.65 V | 4421W | 3242W | 1815W | 1221W | 668W | 362W |
| 1.60 V | 4511W | 3292W | 1825W | 1229W | 669W | 363W |
ROS2-3300
OPZS (FLOODED)Specifications
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 3300 Ah (C10) |
| Energy | 6600 Wh |
| Cell number | 1 |
| Charge Voltage (25°C) | Cycle use: 2.35-2.40V (-5mV/ºC/cell) Float use: 2.20-2.24V (-3mV/ºC/cell) |
| Max. Charge Current | 825 A |
| Max. Discharge Current | 6000 A |
| Internal Resistance | 0.15 mΩ |
| Self Discharge | 3 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | SAN |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
ROS2-3300
OPZS (FLOODED)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER ROS2-3300 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 576 mm
- Width: 212 mm
- Height: 771 mm
- Total Height: 826 mm
- Weight: 162 kg
2. Terminal Configuration (F10)
- Terminals: Ensure your system's connectors match the F10 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 2.35-2.40V (-5mV/ºC/cell)
- Float use: 2.20-2.24V (-3mV/ºC/cell)
4. Safety and Storage
Maintenance: Check the electrolyte level and top up only with distilled or demineralised water.
Position: Always upright.
Ventilation: Install in a ventilated room: hydrogen is released during charging.
Storage: Store charged, in a cool and dry place, and recharge periodically.
