ROS2-3000
SERIES ROS · OPZS (FLOODED)The energy tank. 20+ years of proven service life.
The ROS2-3000 is a 2 V, 3000 Ah (10-hour rate) OPzS lead-acid battery from the Rekoser OPzS (Flooded) series. It measures 576 × 212 × 771 mm and weighs 157 kg, with F10 terminals. It stores 6 kWh and delivers up to 4000 A. The energy tank. 20+ years of proven service life. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and Railway Signaling and Infrastructure.
Formerly RKS2-3000.
Main Advantages
- Technology: Vented tubular plates with liquid electrolyte
- Maintenance: Periodic topping up with distilled water required
- Durability: Over 20 years proven design life at 20ºC
- Control: Transparent container for easy electrolyte level monitoring
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 3000 Ah (C10) |
| Energy | 6000 Wh |
| Weight | 157 kg |
| Terminal | F10 |
| Dimensions | 576 × 212 × 771 mm |
Main Applications
Quality Standards
ROS2-3000
OPZS (FLOODED)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR | 100HR |
|---|---|---|---|---|---|---|---|---|---|---|
| 1.90 V | 958A | 871A | 792A | 775A | 897A | 567A | 417A | 273A | 150A | 38.1A |
| 1.85 V | 1034A | 991A | 974A | 970A | 1020A | 627A | 489A | 285A | 157A | 40.5A |
| 1.80 V | 1651A | 1584A | 1550A | 1334A | 1311A | 768A | 519A | 300A | 165A | 42A |
| 1.75 V | 1982A | 1901A | 1843A | 1526A | 1461A | 795A | 534A | 309A | 173A | 42A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR | 100HR |
|---|---|---|---|---|---|---|---|---|---|---|
| 1.90 V | 1974W | 1795W | 1612W | 1558W | 1725W | 1233W | 894W | 564W | 302W | 82.6W |
| 1.85 V | 2132W | 2045W | 1986W | 1935W | 1962W | 1290W | 993W | 612W | 329W | 86W |
| 1.80 V | 3404W | 3267W | 2800W | 2591W | 2571W | 1641W | 1134W | 660W | 342W | 88.1W |
| 1.75 V | 4085W | 3919W | 2871W | 2609W | 2592W | 1737W | 1185W | 687W | 351W | 88.9W |
ROS2-3000
OPZS (FLOODED)Specifications
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 3000 Ah (C10) |
| Energy | 6000 Wh |
| Cell number | 1 |
| Charge Voltage (25°C) | Cycle use: 2.35-2.40V (-5mV/ºC/cell) Float use: 2.21-2.25V (-3mV/ºC/cell) |
| Max. Charge Current | 500 A |
| Max. Discharge Current | 4000 A |
| Internal Resistance | 0.35 mΩ |
| Self Discharge | 3 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | SAN |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
ROS2-3000
OPZS (FLOODED)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER ROS2-3000 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 576 mm
- Width: 212 mm
- Height: 771 mm
- Total Height: 826 mm
- Weight: 157 kg
2. Terminal Configuration (F10)
- Terminals: Ensure your system's connectors match the F10 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 2.35-2.40V (-5mV/ºC/cell)
- Float use: 2.21-2.25V (-3mV/ºC/cell)
4. Safety and Storage
Maintenance: Check the electrolyte level and top up only with distilled or demineralised water.
Position: Always upright.
Ventilation: Install in a ventilated room: hydrogen is released during charging.
Storage: Store charged, in a cool and dry place, and recharge periodically.
