ROS2-100
SERIES ROS · OPZS (FLOODED)The energy tank. 20+ years of proven service life.
The ROS2-100 is a 2 V, 100 Ah (10-hour rate) OPzS lead-acid battery from the Rekoser OPzS (Flooded) series. It measures 103 × 206 × 354 mm and weighs 8.5 kg, with F10 terminals. It stores 200 Wh and delivers up to 800 A. The energy tank. 20+ years of proven service life. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and Railway Signaling and Infrastructure.
Formerly RKS2-100.
Main Advantages
- Technology: Vented tubular plates with liquid electrolyte
- Maintenance: Periodic topping up with distilled water required
- Durability: Over 20 years proven design life at 20ºC
- Control: Transparent container for easy electrolyte level monitoring
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 100 Ah (C10) |
| Energy | 200 Wh |
| Weight | 8.5 kg |
| Terminal | F10 |
| Dimensions | 103 × 206 × 354 mm |
Main Applications
Quality Standards
ROS2-100
OPZS (FLOODED)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR | 100HR |
|---|---|---|---|---|---|---|---|---|---|---|
| 1.90 V | 39.9A | 36.3A | 33A | 32.3A | 29.9A | 18.9A | 13.9A | 9.1A | 5.01A | 1.27A |
| 1.85 V | 43.1A | 41.3A | 40.6A | 40.4A | 34A | 20.9A | 16.3A | 9.5A | 5.23A | 1.35A |
| 1.80 V | 68.8A | 66A | 64.6A | 55.6A | 43.7A | 25.6A | 17.3A | 10A | 5.5A | 1.4A |
| 1.75 V | 82.6A | 79.2A | 76.8A | 63.6A | 48.7A | 26.5A | 17.8A | 10.3A | 5.78A | 1.43A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR | 100HR |
|---|---|---|---|---|---|---|---|---|---|---|
| 1.90 V | 77.4W | 70.4W | 63.2W | 61.1W | 57.5W | 41.1W | 29.8W | 18.8W | 10.1W | 2.75W |
| 1.85 V | 83.6W | 80.2W | 77.9W | 75.9W | 65.4W | 43W | 33.1W | 20.4W | 11W | 2.87W |
| 1.80 V | 134W | 128W | 110W | 102W | 85.4W | 54.7W | 37.8W | 22W | 11.4W | 2.94W |
| 1.75 V | 160W | 154W | 113W | 102W | 86.4W | 57.9W | 39.5W | 22.9W | 11.7W | 2.96W |
ROS2-100
OPZS (FLOODED)Specifications
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 100 Ah (C10) |
| Energy | 200 Wh |
| Cell number | 1 |
| Charge Voltage (25°C) | Cycle use: 2.35-2.40V (-5mV/ºC/cell) Float use: 2.21-2.25V (-3mV/ºC/cell) |
| Max. Charge Current | 20 A |
| Max. Discharge Current | 800 A |
| Internal Resistance | 0.35 mΩ |
| Self Discharge | 3 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | SAN |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
ROS2-100
OPZS (FLOODED)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER ROS2-100 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 103 mm
- Width: 206 mm
- Height: 354 mm
- Total Height: 409 mm
- Weight: 8.5 kg
2. Terminal Configuration (F10)
- Terminals: Ensure your system's connectors match the F10 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 2.35-2.40V (-5mV/ºC/cell)
- Float use: 2.21-2.25V (-3mV/ºC/cell)
4. Safety and Storage
Maintenance: Check the electrolyte level and top up only with distilled or demineralised water.
Position: Always upright.
Ventilation: Install in a ventilated room: hydrogen is released during charging.
Storage: Store charged, in a cool and dry place, and recharge periodically.
