RDG12-40
SERIES RDG · DEEP GELDeep cycling with full recovery from deep discharge.
The RDG12-40 is a 12 V, 40 Ah (10-hour rate) GEL Deep Cycle lead-acid battery from the Rekoser Deep Gel series. It measures 197 × 165 × 170 mm and weighs 13 kg, with F14 terminals. It stores 480 Wh and delivers up to 400 A. Deep cycling with full recovery from deep discharge. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and UPS and Data Centers.
Formerly RKG12-40.
Main Advantages
- Recovery: Superior performance after deep discharges
- Stable: Low electrolyte stratification
- Longevity: Excellent cycle life in harsh conditions
- Gel Tech: Thixotropic gel electrolyte
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 40 Ah (C10) |
| Energy | 480 Wh |
| Weight | 13 kg |
| Terminal | F14 |
| Dimensions | 197 × 165 × 170 mm |
Main Applications
Quality Standards
RDG12-40
DEEP GELGraphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 62.9A | 56.4A | 51.4A | 36.1A | 23.3A | 10.3A | 6.93A | 3.9A | 2.05A |
| 10.80 V | 73.5A | 62.6A | 56.4A | 38.2A | 24.4A | 10.7A | 7.1A | 4A | 2.1A |
| 10.50 V | 83.1A | 68.9A | 60.4A | 40A | 25.2A | 10.9A | 7.27A | 4.08A | 2.14A |
| 10.20 V | 95.6A | 74.1A | 65.1A | 41.4A | 25.7A | 11.1A | 7.37A | 4.14A | 2.18A |
| 10.02 V | 107A | 81.6A | 68.9A | 43A | 26.3A | 11.2A | 7.42A | 4.19A | 2.23A |
| 9.60 V | 120A | 88.5A | 73.1A | 45A | 27A | 11.3A | 7.53A | 4.24A | 2.28A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 118W | 107W | 98.1W | 69.5W | 45.2W | 20.3W | 13.7W | 7.79W | 4.12W |
| 10.80 V | 136W | 118W | 107W | 72.9W | 46.8W | 20.8W | 13.9W | 7.95W | 4.19W |
| 10.50 V | 152W | 128W | 113W | 75.5W | 47.9W | 21W | 14.2W | 8.04W | 4.24W |
| 10.20 V | 173W | 136W | 121W | 77.6W | 48.6W | 21.2W | 14.2W | 8.09W | 4.3W |
| 10.02 V | 191W | 148W | 127W | 80W | 49.4W | 21.3W | 14.3W | 8.14W | 4.36W |
| 9.60 V | 211W | 159W | 133W | 83.2W | 50.4W | 21.4W | 14.3W | 8.19W | 4.43W |
RDG12-40
DEEP GELSpecifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 40 Ah (C10), 42 Ah (C20) |
| Energy | 480 Wh |
| Cell number | 6 |
| Charge Voltage (25°C) | Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A Float use: 13.6-13.8V (-20mV/C) |
| Max. Charge Current | 10 A |
| Max. Discharge Current | 400 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RDG12-40
DEEP GELQuick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RDG12-40 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 197 mm
- Width: 165 mm
- Height: 170 mm
- Total Height: 170 mm
- Weight: 13 kg
2. Terminal Configuration (F14)
- Terminals: Ensure your system's connectors match the F14 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A
- Float use: 13.6-13.8V (-20mV/C)
4. Safety and Storage
Maintenance: Sealed gel battery, maintenance-free and leak-proof.
Charging: Keep to the stated charge voltage: gel is sensitive to overcharging.
Cycling: Recharge fully after every discharge; never leave it discharged.
Storage: Store charged, in a cool and dry place, and recharge periodically.
