RDG12-225
SERIES RDG · DEEP GELDeep cycling with full recovery from deep discharge.
The RDG12-225 is a 12 V, 225 Ah (10-hour rate) GEL Deep Cycle lead-acid battery from the Rekoser Deep Gel series. It measures 522 × 238 × 218 mm and weighs 64 kg, with F13 terminals. It stores 2.7 kWh and delivers up to 1000 A. Deep cycling with full recovery from deep discharge. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and UPS and Data Centers.
Formerly RKG12-225.
Main Advantages
- Recovery: Superior performance after deep discharges
- Stable: Low electrolyte stratification
- Longevity: Excellent cycle life in harsh conditions
- Gel Tech: Thixotropic gel electrolyte
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 225 Ah (C10) |
| Energy | 2700 Wh |
| Weight | 64 kg |
| Terminal | F13 |
| Dimensions | 522 × 238 × 218 mm |
Main Applications
Quality Standards
RDG12-225
DEEP GELGraphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 336A | 304A | 280A | 199A | 115A | 58.1A | 39A | 21.9A | 11.5A |
| 10.80 V | 393A | 338A | 308A | 211A | 121A | 60.1A | 39.9A | 22.5A | 11.8A |
| 10.50 V | 444A | 372A | 330A | 221A | 125A | 61.3A | 40.9A | 23A | 12A |
| 10.20 V | 511A | 400A | 355A | 228A | 127A | 62.3A | 41.4A | 23.3A | 12.3A |
| 10.02 V | 572A | 441A | 376A | 237A | 130A | 63A | 41.8A | 23.6A | 12.6A |
| 9.60 V | 642A | 478A | 399A | 248A | 134A | 63.8A | 42.3A | 23.9A | 12.8A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 633W | 579W | 536W | 383W | 252W | 114W | 77.1W | 43.8W | 23.2W |
| 10.80 V | 727W | 635W | 582W | 402W | 261W | 117W | 78.4W | 44.7W | 23.6W |
| 10.50 V | 812W | 690W | 618W | 416W | 267W | 118W | 79.6W | 45.2W | 23.9W |
| 10.20 V | 922W | 735W | 659W | 428W | 270W | 119W | 80W | 45.5W | 24.2W |
| 10.02 V | 1020W | 800W | 691W | 441W | 275W | 120W | 80.2W | 45.8W | 24.5W |
| 9.60 V | 1129W | 859W | 728W | 459W | 281W | 120W | 80.6W | 46.1W | 24.9W |
RDG12-225
DEEP GELSpecifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 225 Ah (C10) |
| Energy | 2700 Wh |
| Cell number | 6 |
| Charge Voltage (25°C) | Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A Float use: 13.6-13.8V (-20mV/C) |
| Max. Charge Current | 56 A |
| Max. Discharge Current | 1000 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RDG12-225
DEEP GELQuick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RDG12-225 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 522 mm
- Width: 238 mm
- Height: 218 mm
- Total Height: 222 mm
- Weight: 64 kg
2. Terminal Configuration (F13)
- Terminals: Ensure your system's connectors match the F13 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A
- Float use: 13.6-13.8V (-20mV/C)
4. Safety and Storage
Maintenance: Sealed gel battery, maintenance-free and leak-proof.
Charging: Keep to the stated charge voltage: gel is sensitive to overcharging.
Cycling: Recharge fully after every discharge; never leave it discharged.
Storage: Store charged, in a cool and dry place, and recharge periodically.
