RFT12-100
SERIES RFT · FRONT TERMINAL (AGM)Space optimisation and front-access connection for racks.
The RFT12-100 is a 12 V, 100 Ah (10-hour rate) AGM lead-acid battery from the Rekoser Front Terminal (AGM) series. It measures 395 × 110 × 285 mm and weighs 31 kg, with F14 terminals. It stores 1.2 kWh and delivers up to 800 A. Space optimisation and front-access connection for racks. Typical applications: Telecommunications and Base Stations and UPS and Data Centers.
Formerly RKE12-100FT.
Main Advantages
- Front terminal: Connect and measure without removing the unit
- 19'' rack: Format designed for cabinets and racks
- Long life: EUROBAT class above 12 years
- AGM technology: Sealed and maintenance-free
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 100 Ah (C10) |
| Energy | 1200 Wh |
| Weight | 31 kg |
| Terminal | F14 |
| Dimensions | 395 × 110 × 285 mm |
Main Applications
Quality Standards
RFT12-100
FRONT TERMINAL (AGM)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 142A | 121A | 114A | 81.9A | 52.4A | 24.7A | 16.2A | 9.65A | 5A |
| 10.80 V | 165A | 134A | 125A | 86.8A | 54A | 25.9A | 17A | 10A | 5.3A |
| 10.20 V | 187A | 147A | 134A | 90.8A | 56.7A | 26.4A | 17.2A | 10.3A | 5.33A |
| 10.50 V | 215A | 158A | 145A | 94.1A | 57.9A | 26.8A | 17.4A | 10.2A | 5.4A |
| 10.02 V | 241A | 174A | 153A | 97.8A | 59.2A | 27.1A | 17.5A | 10.5A | 5.45A |
| 9.60 V | 270A | 189A | 163A | 102A | 60.8A | 27.5A | 17.8A | 10.6A | 5.5A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 267W | 229W | 218W | 158W | 102W | 48.4W | 32.1W | 19.3W | 10.1W |
| 10.80 V | 306W | 251W | 237W | 165W | 104W | 50.4W | 33.4W | 19.9W | 10.6W |
| 10.20 V | 342W | 273W | 252W | 172W | 108W | 50.9W | 33.5W | 20.1W | 10.6W |
| 10.50 V | 388W | 291W | 268W | 176W | 109W | 51.3W | 33.5W | 20.2W | 10.6W |
| 10.02 V | 430W | 317W | 281W | 182W | 111W | 51.6W | 33.7W | 20.3W | 10.7W |
| 9.60 V | 475W | 340W | 297W | 189W | 113W | 51.8W | 33.9W | 20.5W | 10.7W |
RFT12-100
FRONT TERMINAL (AGM)Specifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 100 Ah (C10), 105 Ah (C20) |
| Energy | 1200 Wh |
| Cell number | 6 |
| Charge Voltage (25°C) | Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A Float use: 13.6-13.8V (-20mV/C) |
| Max. Charge Current | 25 A |
| Max. Discharge Current | 800 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 25 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RFT12-100
FRONT TERMINAL (AGM)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RFT12-100 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 395 mm
- Width: 110 mm
- Height: 285 mm
- Total Height: 285 mm
- Weight: 31 kg
2. Terminal Configuration (F14)
- Terminals: Ensure your system's connectors match the F14 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A
- Float use: 13.6-13.8V (-20mV/C)
4. Safety and Storage
Maintenance: Sealed AGM technology, maintenance-free and leak-proof.
Position: Can be installed in any orientation, except inverted.
Storage: Store charged, in a cool and dry place, and recharge periodically.
Nearby models
RFT12-110 (12 V · 110 Ah) · See all RFT series models
The same battery in other series: RHP12-100 (RHP Series – High Performance (AGM))
