Maximum AGM longevity (2V). Critical infrastructure.
The RXL2-100 is a 2 V, 100 Ah (20-hour rate) AGM lead-acid battery from the Rekoser eXtended Long Life (AGM 2V) series. It measures 171 × 72 × 206 mm and weighs 5.6 kg, with F10 terminals. It stores 200 Wh and delivers up to 500 A. Maximum AGM longevity (2V). Critical infrastructure. Typical applications: Railway Signaling and Infrastructure, Power Generation and UPS and Data Centers.
Formerly RKE2-100.
Main Advantages
- Format: 2V single cells for modular configuration
- Design Life: 20 years ultra-long life
- Construction: Thick plates for extended service
- Stability: Excellent performance in floating use
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 100 Ah (C20) |
| Energy | 200 Wh |
| Weight | 5.6 kg |
| Terminal | F10 |
| Dimensions | 171 × 72 × 206 mm |
Main Applications
Quality Standards
RXL2-100
EXTENDED LONG LIFE (AGM 2V)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|
| 1.80 V | 116A | 80.4A | 54.7A | 24.7A | 17.3A | 10A | 5.25A |
| 1.75 V | 123A | 83.4A | 56.5A | 25.5A | 17.8A | 10.1A | 5.29A |
| 1.70 V | 127A | 85.5A | 57.6A | 25.7A | 17.9A | 10.1A | 5.32A |
| 1.65 V | 132A | 88.2A | 59.1A | 25.9A | 18A | 10.2A | 5.33A |
| 1.60 V | 135A | 90A | 60A | 26A | 18.2A | 10.2A | 5.34A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|
| 1.80 V | 212W | 150W | 104W | 48.5W | 34W | 19.9W | 10.5W |
| 1.75 V | 224W | 156W | 107W | 50W | 35.1W | 20W | 10.6W |
| 1.70 V | 232W | 160W | 109W | 50.3W | 35.3W | 20.2W | 10.6W |
| 1.65 V | 241W | 165W | 112W | 50.7W | 35.6W | 20.2W | 10.7W |
| 1.60 V | 247W | 168W | 114W | 51W | 35.8W | 20.3W | 10.7W |
RXL2-100
EXTENDED LONG LIFE (AGM 2V)Specifications
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 100 Ah (C20) |
| Energy | 200 Wh |
| Cell number | 1 |
| Charge Voltage (25°C) | Cycle use: 2.35-2.40V (-5mV/C) Float use: 2.25-2.29V (-3mV/C) |
| Max. Charge Current | 20 A |
| Max. Discharge Current | 500 A |
| Internal Resistance | 0.9 mΩ |
| Self Discharge | 3 % of capacity per month at 25 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RXL2-100
EXTENDED LONG LIFE (AGM 2V)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RXL2-100 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 171 mm
- Width: 72 mm
- Height: 206 mm
- Total Height: 211 mm
- Weight: 5.6 kg
2. Terminal Configuration (F10)
- Terminals: Ensure your system's connectors match the F10 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 2.35-2.40V (-5mV/C)
- Float use: 2.25-2.29V (-3mV/C)
4. Safety and Storage
Maintenance: Sealed AGM technology, maintenance-free and leak-proof.
Position: Can be installed in any orientation, except inverted.
Storage: Store charged, in a cool and dry place, and recharge periodically.
