RDC12-33
SERIES RDC · DEEP CYCLE (AGM)Endurance for frequent charge/discharge cycling.
The RDC12-33 is a 12 V, 33 Ah (10-hour rate) AGM Deep Cycle lead-acid battery from the Rekoser Deep Cycle (AGM) series. It measures 195 × 130 × 155 mm and weighs 10.2 kg, with F11 terminals. It stores 396 Wh and delivers up to 400 A. Endurance for frequent charge/discharge cycling. Typical applications: Solar/Wind Energy Systems and Light Electric Vehicles.
Formerly RKC12-33.
Main Advantages
- Cycling: Optimized for more than 400 cycles at 80% DOD
- Materials: Specialized active material and thick plates
- Versatility: Suitable for both motive and stationary use
- Efficiency: High recharge acceptance
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 33 Ah (C10) |
| Energy | 396 Wh |
| Weight | 10.2 kg |
| Terminal | F11 |
| Dimensions | 195 × 130 × 155 mm |
Main Applications
Quality Standards
RDC12-33
DEEP CYCLE (AGM)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 87.4A | 68.4A | 58A | 35.6A | 21.2A | 9.2A | 5.93A | 3.27A | 1.67A |
| 10.80 V | 98.8A | 72.6A | 59.5A | 36.4A | 21.6A | 9.32A | 5.99A | 3.31A | 1.71A |
| 10.50 V | 110A | 76.8A | 60.9A | 37A | 22A | 9.46A | 6.06A | 3.35A | 1.75A |
| 10.20 V | 121A | 80.4A | 62.5A | 37.9A | 22.4A | 9.56A | 6.14A | 3.39A | 1.79A |
| 10.02 V | 130A | 84A | 64.1A | 38.6A | 22.8A | 9.64A | 6.22A | 3.43A | 1.82A |
| 9.60 V | 140A | 87A | 66.4A | 39.5A | 23A | 9.74A | 6.29A | 3.47A | 1.86A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 11.10 V | 165W | 130W | 111W | 68.6W | 41.2W | 17.9W | 11.5W | 6.53W | 3.35W |
| 10.80 V | 183W | 136W | 112W | 69.3W | 41.4W | 18W | 11.6W | 6.57W | 3.42W |
| 10.50 V | 202W | 143W | 114W | 70W | 41.9W | 18.1W | 11.7W | 6.6W | 3.47W |
| 10.20 V | 218W | 148W | 116W | 71W | 42.3W | 18.2W | 11.8W | 6.63W | 3.53W |
| 10.02 V | 232W | 153W | 118W | 71.7W | 42.7W | 18.3W | 11.9W | 6.66W | 3.56W |
| 9.60 V | 247W | 156W | 121W | 73W | 42.9W | 18.4W | 12W | 6.7W | 3.6W |
RDC12-33
DEEP CYCLE (AGM)Specifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 33 Ah (C10) |
| Energy | 396 Wh |
| Cell number | 6 |
| Charge Voltage (25°C) | Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A Float use: 13.6-13.8V (-20mV/C) |
| Max. Charge Current | 10 A |
| Max. Discharge Current | 400 A |
| Internal Resistance | 25 mΩ |
| Self Discharge | 3 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RDC12-33
DEEP CYCLE (AGM)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RDC12-33 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 195 mm
- Width: 130 mm
- Height: 155 mm
- Total Height: 168 mm
- Weight: 10.2 kg
2. Terminal Configuration (F11)
- Terminals: Ensure your system's connectors match the F11 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 14.6-14.8V (-30mV/C), max. Current 2.1A
- Float use: 13.6-13.8V (-20mV/C)
4. Safety and Storage
Maintenance: Sealed AGM technology, maintenance-free and leak-proof.
Cycling: Recharge fully after every discharge; never leave it discharged.
Position: Can be installed in any orientation, except inverted.
Storage: Store charged, in a cool and dry place, and recharge periodically.
