ROS12-220
SERIES ROS · OPZS (FLOODED)The energy tank. 20+ years of proven service life.
The ROS12-220 is a 12 V, 220 Ah (10-hour rate) OPzS lead-acid battery from the Rekoser OPzS (Flooded) series. It measures 522 × 269 × 220 mm and weighs 73.5 kg, with F12 terminals. It stores 2.64 kWh and delivers up to 1160 A. The energy tank. 20+ years of proven service life. Typical applications: Solar/Wind Energy Systems, Electrical Substations, Telecommunications and Base Stations and Railway Signaling and Infrastructure.
Formerly RKS12-220.
Main Advantages
- Technology: Vented tubular plates with liquid electrolyte
- Maintenance: Periodic topping up with distilled water required
- Durability: Over 20 years proven design life at 20ºC
- Control: Transparent container for easy electrolyte level monitoring
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 220 Ah (C10) |
| Energy | 2640 Wh |
| Weight | 73.5 kg |
| Terminal | F12 |
| Dimensions | 522 × 269 × 220 mm |
Main Applications
Quality Standards
ROS12-220
OPZS (FLOODED)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 10.8 V | 225A | 216A | 201A | 161A | 112A | 54.4A | 38.4A | 22A | 11.9A |
| 10.5 V | 239A | 229A | 212A | 167A | 116A | 56.1A | 39.6A | 22.2A | 12A |
| 10.02 V | 250A | 239A | 219A | 171A | 118A | 56.5A | 39.9A | 22.3A | 12A |
| 9.9 V | 260A | 250A | 228A | 177A | 121A | 57.3A | 40.4A | 22.4A | 12.1A |
| 9.6 V | 268A | 257A | 233A | 180A | 123A | 57.6A | 40.7A | 22.4A | 12.1A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|---|---|---|
| 10.8 V | 404W | 389W | 367W | 301W | 213W | 107W | 75.7W | 53.8W | 23.8W |
| 10.5 V | 428W | 412W | 387W | 313W | 220W | 110W | 78W | 44.1W | 23.9W |
| 10.02 V | 447W | 431W | 401W | 320W | 225W | 111W | 78.6W | 44.3W | 24.1W |
| 9.9 V | 466W | 449W | 417W | 331W | 231W | 112W | 79.7W | 44.5W | 24.1W |
| 9.6 V | 480W | 463W | 427W | 337W | 234W | 113W | 80.1W | 44.6W | 24.2W |
ROS12-220
OPZS (FLOODED)Specifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity (25ºC) | 220 Ah (C10) |
| Energy | 2640 Wh |
| Cell number | 6 |
| Charge Voltage (25°C) | Cycle use: 14.1-14.4V (-5mV / o C/ cell) Float use: 13.2-13.5V (-3mV / o C/ cell) |
| Max. Charge Current | 66 A |
| Max. Discharge Current | 1160 A |
| Internal Resistance | 0.35 mΩ |
| Self Discharge | 3 % of capacity per month at 20 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | SAN |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
ROS12-220
OPZS (FLOODED)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER ROS12-220 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 522 mm
- Width: 269 mm
- Height: 220 mm
- Total Height: 220 mm
- Weight: 73.5 kg
2. Terminal Configuration (F12)
- Terminals: Ensure your system's connectors match the F12 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 14.1-14.4V (-5mV / o C/ cell)
- Float use: 13.2-13.5V (-3mV / o C/ cell)
4. Safety and Storage
Maintenance: Check the electrolyte level and top up only with distilled or demineralised water.
Position: Always upright.
Ventilation: Install in a ventilated room: hydrogen is released during charging.
Storage: Store charged, in a cool and dry place, and recharge periodically.
