RXL2-2000
SERIES RXL · EXTENDED LONG LIFE (AGM 2V)Maximum AGM longevity (2V). Critical infrastructure.
The RXL2-2000 is a 2 V, 2000 Ah (10-hour rate) AGM lead-acid battery from the Rekoser eXtended Long Life (AGM 2V) series. It measures 490 × 350 × 345 mm and weighs 120 kg, with F10 terminals. It stores 4 kWh and delivers up to 7000 A. Maximum AGM longevity (2V). Critical infrastructure. Typical applications: Railway Signaling and Infrastructure, Power Generation and UPS and Data Centers.
Formerly RKE2-2000.
Main Advantages
- Format: 2V single cells for modular configuration
- Design Life: 20 years ultra-long life
- Construction: Thick plates for extended service
- Stability: Excellent performance in floating use
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 2000 Ah (C10) |
| Energy | 4000 Wh |
| Weight | 120 kg |
| Terminal | F10 |
| Dimensions | 490 × 350 × 345 mm |
Main Applications
Quality Standards
RXL2-2000
EXTENDED LONG LIFE (AGM 2V)Graphics (25°C)
Constant Discharge Ratings (A) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 1.80 V | 1607A | 1094A | 495A | 345A | 200A | 105A |
| 1.75 V | 1669A | 1129A | 510A | 356A | 201A | 106A |
| 1.70 V | 1710A | 1152A | 514A | 358A | 203A | 106A |
| 1.65 V | 1764A | 1182A | 517A | 361A | 203A | 107A |
| 1.60 V | 1800A | 1200A | 520A | 363A | 204A | 107A |
Constant Discharge Ratings (W) at 25ºC
| F.V / Time | 30MIN | 1HR | 3HR | 5HR | 10HR | 20HR |
|---|---|---|---|---|---|---|
| 1.80 V | 3006W | 2079W | 970W | 680W | 398W | 210W |
| 1.75 V | 3120W | 2145W | 1000W | 701W | 401W | 211W |
| 1.70 V | 3198W | 2189W | 1007W | 706W | 403W | 213W |
| 1.65 V | 3299W | 2246W | 1014W | 711W | 404W | 213W |
| 1.60 V | 3366W | 2280W | 1020W | 715W | 405W | 214W |
RXL2-2000
EXTENDED LONG LIFE (AGM 2V)Specifications
| Nominal Voltage | 2 V |
|---|---|
| Capacity (25ºC) | 2000 Ah (C10) |
| Energy | 4000 Wh |
| Cell number | 1 |
| Charge Voltage (25°C) | Cycle use: 2.35-2.40V (-3mV/C), max. Current 2.1A Float use: 2.25-2.29V (-2mV/C) |
| Max. Charge Current | 400 A |
| Max. Discharge Current | 7000 A |
| Internal Resistance | 0.18 mΩ |
| Self Discharge | 3 % of capacity per month at 25 °C |
| Capacity Affected by Temperature | 40 °C: 102 %, 25 °C: 100 %, 0 °C: 85 %, -15 °C: 65 % |
Construction
| Component | Material |
|---|---|
| Container | ABS (Flame Retardant Optional) |
| Cover | ABS (Flame Retardant Optional) |
| Electrolyte | Sulphuric acid |
| Negative | Lead |
| Positive | Lead dioxide |
| Safety Valve | Rubber |
| Sealant | Epoxy Resin |
| Separator | Fibre Glass |
| Terminal | Copper |
RXL2-2000
EXTENDED LONG LIFE (AGM 2V)Quick Installation Guide
To ensure optimal performance and maximize the lifespan of your REKOSER RXL2-2000 battery, follow these assembly and connection guidelines.
1. Space and Dimension Verification
Before proceeding, ensure the receptacle or cabinet of your equipment complies with the unit's physical measurements:
- Length: 490 mm
- Width: 350 mm
- Height: 345 mm
- Total Height: 382 mm
- Weight: 120 kg
2. Terminal Configuration (F10)
- Terminals: Ensure your system's connectors match the F10 type to prevent electrical arcing.
- Polarity: Check the positive and negative markings on the battery before connecting, to prevent short circuits.
3. Charge Parameters
- Cycle use: 2.35-2.40V (-3mV/C), max. Current 2.1A
- Float use: 2.25-2.29V (-2mV/C)
4. Safety and Storage
Maintenance: Sealed AGM technology, maintenance-free and leak-proof.
Position: Can be installed in any orientation, except inverted.
Storage: Store charged, in a cool and dry place, and recharge periodically.
