RKV6-250 (6V 250Ah )

6V 250Ah OPzV Battery

Rekoser Rekoser OPzV battery. The RKV series adopts an Immobilized Gel and Tubular Positive Plate technology. It offers high reliability and stable performance. By using die-casted positive grid and patented active material formula, it exceeds the DIN standard values and offer 20+ years design life in float service. It is very suitable for cyclic use under extreme operating conditions. This series is recommended for telecom outdoor applications, renewable energy systems and other harsh environment applications.

6V 250Ah  OPzV Battery
Rekoser Rekoser opzv-battery RKV0602500 RKV6-250 RKV6-250 6V 250Ah OPzV Battery
Specifications
Nominal Voltage6V
Capacity (25ºC)250Ah @ 10HR
Internal Resistance Approx. 4.7mOhm (fully charged @ 20°C)
Self Discharge Approx. 2% per month @ 20°C
Cell number3 cells
Capacity Affected by Temperature102% (40°C)100% (25°C)85% (0°C)65% (-15°C)
Charge Voltage (25°C)Cycle - 7.05-7.20V (-5mV/ºC/cell)Float - 6.75-6.90V (-3mV/ºC/cell)
Max. Charge Current60A
Max. Discharge Current1250A
Graphics
CHARGE CHARACTERISTICS
DISCHARGE CHARACTERISTIC 25oC
SELF DISCHARGE CHARACTERISTICS
FLOAT VOLTAGE VS FLOAT LIFE
Dimensions and weight
Dimensions (mm) 295x178x408(408)
Weight (kgs) 46.5
Construction
Component Raw Material
Positive Lead dioxide
Negative Lead
Container ABS(UL94-V0 optional)
Cover ABS (Flame Retardant Optional)
Sealant Epoxy Resin
Safety Valve Rubber
Terminal Copper
Separator Fibre Glass
Electrolyte Immobilized Gel
Constant Discharge Ratings (A, W) at 25ºC
F.V / Time30MIN1HR3HR5HR10HR20HR
5.40 V185A346W116A230W60.1A117W43.1A85.0W25.0A49.7W13.2A26.5W
5.25 V192A360W125A273W62.0A121W44.5A87.6W25.1A50.0W13.3A26.6W
5.10 V197A368W127A242W62.3A122W44.7A88.2W25.3A50.3W13.3A26.8W
4.95 V204A380W131A248W62.8A123W45.1A88.8W25.3A50.5W13.5A26.8W
4.80 V207A387W132A252W63.2A124W45.3A89.3W25.5A50.6W13.5A27.0W
