2V100Ah @ 20HR

Rekoser AGM Battery for General Purpose

AGM Battery. Rekoser stationary series, general use, has been specially designed to optimize its life and quality, minimizing maintenance and maximizing self discharge of their properties for longer storage. RKE series is ideal for security and alarm systems, UPS systems,emergency light systems and other small backup applications.

Specifications
Nominal Voltage 2V
Capacity (25ºC) 100Ah @ 20HR
Internal Resistance Fully Charged 0.9 m Ω
Self Discharge 3% of capacity declined per month at 25°C
Cell number 1 cells
Capacity Affected by Temperature 102% (40°C) 100% (25°C) 85% (0°C) 65% (-15°C)
Charge Voltage (25°C) Cycle - 2.35-2.40V (-5mV/C) Float - 2.25-2.29V (-3mV/C)
Max. Charge Current 20A
Max. Discharge Current 500A
Graphics
CHARGE CHARACTERISTICS
DISCHARGE CHARACTERISTIC 25oC
SELF DISCHARGE CHARACTERISTICS
FLOAT VOLTAGE VS FLOAT LIFE
awaiting.png agm_battery_2v_100ah_rke2-100_terminal.png
Dimensions and weight
Dimensions (mm) 171x72x206(211)
Weight (kgs) 5.6
Construction
Component Raw Material
Positive Lead dioxide
Negative Lead
Container ABS (Flame Retardant Optional)
Cover ABS (Flame Retardant Optional)
Sealant Epoxy Resin
Safety Valve Rubber
Terminal Copper
Separator Fibre Glass
Electrolyte Sulphuric acid
Constant Discharge Ratings (A, W) at 25ºC
F.V / Time 15MIN 30MIN 1HR 3HR 5HR 10HR 20HR
1.80 V 116A212W80.4A150W54.7A104W24.7A48.5W17.3A34.0W10.0A19.9W5.25A10.5W
1.75 V 123A224W83.4A156W56.5A107W25.5A50.0W17.8A35.1W10.1A20.0W5.29A10.6W
1.70 V 127A232W85.5A160W57.6A109W25.7A50.3W17.9A35.3W10.1A20.2W5.32A10.6W
1.65 V 132A241W88.2A165W59.1A112W25.9A50.7W18.0A35.6W10.2A20.2W5.33A10.7W
1.60 V 135A247W90.0A168W60.0A114W26.0A51.0W18.2A35.8W10.2A20.3W5.34A10.7W
